Material: | Steel | Specification: | Custom |
---|---|---|---|
Delivery Time: | 15-45 Days | Origin: | Qingdao |
File Formats: | Solid Works, Autocad(Dxf, Dwg), Pdf | Sample Time: | 7 Days If Standard Parts We Have |
Processing: | Cutting,welding,assembly,galvanizing,painting,flaw Detection,transporting | Design: | Do As The Customer's Drawing |
Highlight: | Eco Friendly Steel Bridge,custom steel bridge Galvanized,steel bridge construction Sustainable |
Attribute | Value |
---|---|
Material | Steel |
Specification | Custom |
Delivery Time | 15-45 Days |
Origin | Qingdao |
File Formats | Solid Works, Autocad(Dxf, Dwg), Pdf |
Sample Time | 7 Days If Standard Parts We Have |
Processing | Cutting, welding, assembly, galvanizing, painting, flaw detection, transporting |
Design | Do as the customer's drawing |
Our eco-friendly steel structure bridge is a highly durable and load-bearing solution designed for highways, railways, and pedestrian crossings. Constructed using high-strength steel girders, trusses, or arch systems, it ensures superior structural integrity and resistance to heavy traffic, seismic activity, and extreme weather conditions.
NO. | Internal Force | Structure Form |
---|---|---|
200 | Standard Truss Moment (kN.m) | 1034.3 | 2027.2 | 2978.8 | 3930.3 | 2165.4 | 4244.2 | 6236.4 | 8228.6 |
200 | Standard Truss Shear (kN) | 222.1 | 435.3 | 639.6 | 843.9 | 222.1 | 435.3 | 639.6 | 843.9 |
201 | High Bending Truss Moment (kN.m) | 1593.2 | 3122.8 | 4585.5 | 6054.3 | 3335.8 | 6538.2 | 9607.1 | 12676.1 |
202 | High Bending Truss Shear (kN) | 348 | 696 | 1044 | 1392 | 348 | 696 | 1044 | 1392 |
203 | Shear Force of Super High Shear Truss (kN) | 509.8 | 999.2 | 1468.2 | 1937.2 | 509.8 | 999.2 | 1468.2 | 1937.2 |
Structure | Geometric Characteristics |
---|---|
SS | Chord Area: 25.48 cm² | Section Properties: 5437 cm³ | Moment of Inertia: 580174 cm⁴ |
SSR | Chord Area: 50.96 cm² | Section Properties: 10875 cm³ | Moment of Inertia: 1160348 cm⁴ |
DS | Chord Area: 50.96 cm² | Section Properties: 10875 cm³ | Moment of Inertia: 1160348 cm⁴ |
DSR1 | Chord Area: 76.44 cm² | Section Properties: 16312 cm³ | Moment of Inertia: 1740522 cm⁴ |
TS | Chord Area: 76.44 cm² | Section Properties: 16312 cm³ | Moment of Inertia: 1740522 cm⁴ |
QS | Chord Area: 101.92 cm² | Section Properties: 21750 cm³ | Moment of Inertia: 2320696 cm⁴ |
