Rust Resistance Commercial Steel Building Prebuilt Metal Prefabricated Steel Garage
Product Specifications
| Material | Steel |
| Specification | Custom |
| Delivery Time | 15-45 Days |
| Grade | A |
| File Formats | Dwg and Pdf |
| Sample Time | 7 Days If Standard Parts We Have |
| Processing | Cutting, welding, assembly, galvanizing, painting, flaw detection, transporting |
| Feature | Earthquake resistance |
Product Description
Our commercial steel buildings are modern, high-performance structures designed for retail spaces, office buildings, shopping centers, and other business applications. Utilizing precision-engineered steel framing, they offer unmatched strength, flexibility, and aesthetic appeal.
Steel construction ensures long-term durability, fire resistance, and energy efficiency while allowing for expansive floor plans and customizable layouts. The prefabrication process speeds up construction timelines, making it a cost-effective and sustainable choice for commercial developments.
Technical Specifications
| Main Steel Frame |
| Column | Q235, Q355 Welded H Section Steel |
| Beam | Q235, Q355 Welded H Section Steel |
| Secondary Frame |
| Purlin | Q235, Q355 C and Z purlin |
| Knee brace | Q235, Q355 Angle Steel |
| Tie Rod | Q235, Q355 Circular Steel Pipe |
| Brace | Q235, Q355 Round Bar |
| Vertical and Horizontal Support | Q235, Q355 Angle Steel, Round Bar or Steel Pipe |
| Maintenance System |
| Roof Panel | EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / PU Sandwich Panel / Steel Sheet |
| Wall Panel | Sandwich Panel / Corrugated Steel Sheet |
| Accessories |
| Window | Aluminium Alloy Window / PVC Window / Sandwich Panel Window |
| Door | Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door |
| Rainspout | PVC |
| Live load on Roof | 120kg/Sqm (Color steel panel surrounded) |
| Wind Resistance Grade | 12 Grades |
| Earthquake-resistance | 8 Grades |
| Structure Usage | Up to 50 years |
| Finishing Options | Vast array of colors and textures available |
| Paint Options | Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized |
Frequently Asked Questions
Q1: Are you trading company or manufacturer?
A: We are a manufacturer engaging in the field of metal products for more than 20 years.
Q2: How much is the freight?
A: We will decide according to your mode of shipping and quantity. Please provide specific mode of transportation (by sea or air) and which port or airport to arrive at.
Q3: Do you accept retail order? What is the MOQ required?
A: Yes, we accept retail order. MOQ is negotiable, feel free to contact us for discussion.
Q4: Do you provide ODM/OEM service?
A: Yes. OEM&ODM is available. You can show us your design plan or original sample. We handle everything from concept to finished goods including design, prototype reviewing, tooling and production.
Q5: Can you provide samples?
A: Yes. We can ship samples via DHL, UPS, Fedex, TNT, EMS etc. Contact us for details.
Q6: How do I place an order?
A: Please provide the following information:
- Product information: specifications, quantity, delivery requirements
- Payment details
- Shipping information: name, address, phone number, shipping requirements
- Freight forwarder contact if applicable
- Official purchase order or we can provide proforma invoices
Contact Us
Please provide the following requirements for your custom steel building:
1. Width __________ M
2. Length __________ M
3. Space distance between columns: __________ M
4. Eave high __________ M
5. Brick wall or concrete wall high (if any) __________ M
6. Roof slope grade __________ (° or %)
7. Ventilation: 1) no 2) normal 3) natural 4) ventilator
8. Wall and roof: 1) EPS sandwich panel 2) PU panel 3) rock wool panel 4) steel sheet thickness: __________
9. Door: 1) sandwich panel sliding door 2) rolling door size: __________
10. Window: 1) aluminium window 2) PVC window size: __________
11. Lighting: 1) skylight board 2) thickness: __________
12. Draining: 1) natural draining 2) gutter
13. Crane: 1) yes 2) no 3) capacity _____ T
