Q235 Hot Dip Galvanized Steel Structure High Rise Large Span Steel Structure (120kg/Sqm)
Product Specifications
| Attribute | Value |
| Product Name | Large Span Prefabricated Steel Buildings Prefab Metal Warehouse Workshop Office Building |
| Material | Steel |
| Specification | Custom |
| Delivery Time | 15-45 Days |
| OEM/ODM | OEM, ODM |
| File Formats | Solid Works, Autocad (Dxf, Dwg), Pdf |
| Sample Time | 7 Days (If Standard Parts We Have) |
| Processing | Cutting, welding, assembly, galvanizing, painting, flaw detection, transporting |
| Feature | Earthquake resistance |
| Quality | Quality Guarantee |
High Span Q235 Modular High Rise Construction Modern Steel Structure
With the development of national economy and the acceleration of urbanization process, steel structures are increasingly being used in construction. Our steel structures offer high strength, light weight, excellent seismic performance, short construction periods, strong plasticity, and energy efficiency. They are widely used in industrial plants, municipal infrastructure, cultural/educational/sports buildings, power plants, bridges, offshore oil engineering, and aerospace industries.
| Component | Specification |
| Main Steel Frame |
| Column | Q235, Q355 Welded H Section Steel |
| Beam | Q235, Q355 Welded H Section Steel |
| Secondary Frame |
| Purlin | Q235, Q355 C and Z purlin |
| Knee brace | Q235, Q355 Angle Steel |
| Tie Rod | Q235, Q355 Circular Steel Pipe |
| Brace | Q235, Q355 Round Bar |
| Vertical and Horizontal Support | Q235, Q355 Angle Steel, Round Bar or Steel Pipe |
| Maintenance System |
| Roof Panel | EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / PU Sandwich Panel / Steel Sheet |
| Wall Panel | Sandwich Panel / Corrugated Steel Sheet |
| Performance Specifications |
| Live load on Roof | 120kg/Sqm (Color steel panel surrounded) |
| Wind Resistance Grade | 12 Grades |
| Earthquake-resistance | 8 Grades |
| Structure Usage | Up to 50 years |
| Finishing Options | Vast array of colors and textures available |
| Paint Options | Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized |
Frequently Asked Questions
Q1: Are you trading company or manufacturer?
A: We are a manufacturer with over 20 years of experience in metal products.
Q2: How much is the freight?
A: Freight costs depend on shipping method and quantity. Please provide specific transportation details (sea/air) and destination port/airport.
Q3: Do you accept retail order? What is the MOQ required?
A: Yes, we accept retail orders. Minimum order quantity is negotiable.
Q4: Do you provide ODM/OEM service?
A: Yes. We offer complete OEM/ODM services from design to production.
Q5: Can you provide samples?
A: Yes. Samples can be shipped via DHL, UPS, Fedex, TNT, or EMS.
Q6: How do I place an order?
A: Please provide product specifications, quantity, delivery requirements, payment and shipping information, along with any freight forwarder details.
